SRP1040-3R3M

3.3uH ±20% 10A

Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Iron 10A 10mOhm DCR T/R

得捷:
FIXED IND 3.3UH 10A 10 MOHM SMD

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power SRP1040-3R3M surface mount inductor from Bourns is perfect for you! This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 150 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This SMD inductor has a maximum DC current of 10 A with a maximum resistance of 10m Ohm. This device is made with wirewound technology. It has a tolerance of 20%. It has an inductance of 3.3u H. Its test frequency is 100K Hz. This product is 11.8 mm long, 4.2 mm tall and 10.5 mm deep.

安富利:
Ind Power Shielded Wirewound 3.3uH 20% 100KHz Iron 10A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Iron 10A 10mOhm DCR T/R

Verical:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Iron 10A 0.01Ohm DCR T/R

Newark:
# BOURNS  SRP1040-3R3M  Surface Mount Power Inductor, SRP1040 Series, 3.3 µH, 10 A, 14 A, Shielded, 0.01 ohm

MASTER:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Iron 10A 0.01Ohm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Iron 10A 10mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Iron 10A 0.01Ohm DCR T/R
