Conn Socket Strip SKT 60POS 2mm Solder ST Thru-Hole Tube
60 位置 插座 0.079"（2.00mm） 通孔 镀金
得捷:
CONN RCPT 60POS 0.079 GOLD PCB
艾睿:
Safety is an important concern when designing electronic devices. Samtec&s;s socket strip SQW-120-01-F-T header connector helps protect your equipment from accidental shortages. This SKT connector&s;s 60 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2 mm. It has a straight body orientation. It has a socket type gender. It has a maximum voltage rating of 500 VAC. This is a 3-row connector. This device has a maximum current rating of 3.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 40.12 mm long, 6.35 mm tall and 6 mm deep. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. SQW-120-01-F-T is housed in black liquid crystal polymer.
Chip1Stop:
Conn Socket Strip SKT 60 POS 2mm Solder ST Thru-Hole Tube
Verical:
Conn Socket Strip SKT 60 POS 2mm Solder ST Top Entry Thru-Hole Tube
