104433-3

Conn Unshrouded Header HDR 6POS 2.54mm Solder ST Thru-Hole

06 MODII HDR DRST B/A W/HD

Product Highlights

Connector

Header Type = Breakaway

6 Positions

Mating Post Length = 8.08 mm

2.54 mm Centerline

得捷:
CONN HEADER VERT 6POS 2.54MM

贸泽:
Headers & Wire Housings 06 MODII HDR DRST B/A W/HD

艾睿:
Safety is an important concern when designing electronic devices. TE Connectivity&s;s unshrouded 104433-3 header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. This is a 2-row connector. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 3 A/contact. 104433-3 is housed in black thermoplastic. This product is 7.21 mm long, 10.36 mm tall and 4.87 mm deep. This connector has an operating temperature of -65 to 105 °C. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header M 6 POS 2.54mm Solder ST Top Entry Thru-Hole Automotive Carton

MASTER:
HEADER ASSY, MOD II, BREAKAWAY, DBL ROW,.100X.100 C VERT, .025 SQ POSTS, WITH RETENTION FEATURE

Powell:
.100 inch AMPMODU Headers

Online Components:
06 MODII HDR DRST B/A W/HD

Electro Sonic:
06 MODII HDR DRST B/A W/HD
