Phoenix Contact COMBICON MSTB 系列 5mm 节距 2 路 母 绿色 插头 1912074, 螺钉端接
2 针位端子块 插头,母插口 0.197"(5.00mm) - 180° 自由悬挂
得捷:
TERM BLOCK PLUG 2POS STR 5MM
欧时:
Phoenix Contact 1912074 COMBICON MSTB 系列 5mm 节距 2 路 母 插头, 螺钉端接 绿色
贸泽:
可插拔接线端子 2 Pos 5mm pitch Plug 24-12 AWG Screw
艾睿:
Conn Terminal Block F 2 POS 5mm Screw RA Panel Mount 16A
Verical:
Conn Terminal Block F 2 POS 5mm Screw RA Panel Mount 16A
MASTER:
PCB connector - nominal current: 16 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 2 - pitch: 5 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin
Online Components:
Conn Terminal Block F 2 POS 5mm Screw RA Panel Mount 16A
Electro Sonic:
PCB connector - nominal current: 16 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
触点数 2
线规 12AWG ~ 30AWG
触点电镀 Tin
额定电流 16 A
排数 1
电路数 2
易燃性等级 UL 94 V-0
针脚数 2
额定电流Max 16 A
额定电压Max 320 V
额定电压 630 V
工作电压Max 320 V
长度 29.4 mm
宽度 18.2 mm
高度 15 mm
外壳颜色 Green
颜色 Green
触点材质 Copper Alloy
外壳材质 Plastic
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536694040
