SRU8043-4R7Y

SHIELDED SMD功率电感 Shielded SMD Power Inductors

Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 13Q-Factor Ferrite 4.6A 17mOhm DCR 3131 T/R

立创商城:
4.7uH ±30% 4.6A 17mΩ

得捷:
FIXED IND 4.7UH 4.6A 17 MOHM SMD

艾睿:
Use this power SRU8043-4R7Y surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This SMD inductor has a maximum DC current of 4.6 A with a maximum resistance of 17m Ohm. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 36M Hz. This device utilizes wirewound technology. It has an inductance of 4.7u H. This product is 8.3 mm long, 4.6 mm tall and 8.3 mm deep.

安富利:
Ind Power Shielded Wirewound 4.7uH 30% 100KHz 13Q-Factor Ferrite 4.6A T/R

Chip1Stop:
Ind Power Shielded Wirewound 4.7uH 30% 100KHz 13Q-Factor Ferrite 4.6A T/R

Verical:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 13Q-Factor Ferrite 4.6A 0.017Ohm DCR 3131 T/R

Online Components:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 13Q-Factor Ferrite 4.6A 17mOhm DCR 3131 T/R

Electro Sonic:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 13Q-Factor Ferrite 4.6A 17mOhm DCR 3131 T/R
